Measured from the tip of the rod. Below are recommended popular guide spacing. Every rod blank is different. The recommendations may be altered to suit your requirements. Spacing is measured in inches from the tip.
| Length | 1st | 2nd | 3rd | 4th | 5th | 6th | 7th | 8th | 9th | 10th | 11th | 12th | 13th |
| 7' | 4 5/8" | 10 3/4" | 17 7/8" | 25 5/8" | 34 1/8" | 43 1/4" | 54 3/8" | ||||||
| 7 1/2' | 4" | 9 1/2" | 15 3/4" | 23 1/4" | 31 3/4" | 41 1/8" | 51 3/4" | 62 7/8" | |||||
| 8' | 4 3/4" | 16 | 22 7/8" | 30 1/2" | 38 3/8" | 46 3/4" | 55 7/8" | 65 | |||||
| 8 1/2' | 4" | 9 1/2" | 16 1/4" | 23 3/4" | 31 3/4" | 40 3/8" | 49 3/8" | 59 1/2" | 70 3/4" | ||||
| 9' | 4" | 9" | 15 | 22" | 29 5/8" | 37 5/8" | 46 1/4" | 55 1/8" | 65" | 76" | |||
| 9 1/2' | 4" | 8 7/8" | 14 1/2" | 21 1/8" | 29 1/8" | 37 1/2" | 47" | 56 7/8" | 68" | 80" | |||
| 10' | 4 1/8" | 9 1/4" | 14 1/2" | 20 3/4" | 27 1/2" | 34 1/2" | 42 1/4" | 50 1/4" | 56 3/4" | 68 1/4" | 77 1/2" | 88" | |
| 10 1/2' | 4 5/8" | 10 3/8" | 16 1/4" | 22 5/8" | 29 3/8" | 36 3/8" | 43 3/4" | 51 5/8" | 59 7/8" | 69 | 78 1/4" | 88 1/4" | 98 5/8" |
